皮帶輸送機 Belt Conveyor

產品中心 > 皮帶輸送機 Belt Conveyor

皮帶輸送機 Belt Conveyor


皮帶輸送機
Belt Conveyor

皮帶輸送機:
  皮帶輸送機,也叫帶式輸送機或膠帶輸送機,是組成有節奏的流水作業線所不可缺少的經濟型物流輸送設備。皮帶機按其輸送能力可分為重型皮帶機如礦用皮帶輸送機,輕型皮帶機如用在電子、塑料、食品輕工、化工醫藥等行業的皮帶機。皮帶輸送機具有輸送能力強,輸送距離遠,結構簡單易于維護,能方便地實行程序化控制和自動化操作。利用輸送帶的連續或間歇運動來輸送100KG以下的物品包括粉狀、顆粒狀物品,其運行高速、平穩,噪音低,并可以上下坡傳送。

Belt  Conveyor:
  A belt conveyor can be also called ribbon conveyor or rubber belt conveyor. It is an indispensable economical logistic transporting facility to compose a rhythmic assembly line. Belt conveyors can be divided into two types according to the transporting capacity: heavy-duty belt conveyor, such as belt conveyors used in mining ,and light-duty belt conveyor, such as belt conveyors used in electronics, plastic, food industry, chemical industry , medicine and so on. The belt conveyor has the following features: strong transporting capacity, capable of transporting for a long distance, simple structure for easy maintenance and convenient to be controlled by program and operated automatically.  Continuous or intermittent movement of the conveying belt is  utilized to transport materials  weighing less than 100KG ,including  powder and particles, and the belt conveyor  runs at a high speed,  smoothly and steadily ,and  with low noise.  It  can transport up and down the slope.

技術參數Technical  parameters


型號規格
Type

輸送量
Conveying
Capacity

膠帶寬度
Belt width

膠帶速度
Belt speed

最大傾角
Maximum
inclined angle

重量
Weight

長度/電機功率
Length / Electromotor
power


Remarks

(t/h)

(mm)

(m/s)

(o)

(t/條)(ton per belt )

(M/kW)

B1600

800-1600

1600

1.3-3.0

≤18

17.6t/35m

10-20/22-30

20-40/37-45

配Y系列電機、減速機 、振動電機。
不配啟動柜。
Y series motor , decelerator and vibrating motor are configured .
Starter cabinet is not configured.

B1400

650-1300

1400

1.3-3.0

≤18

11.3t/30m

10-20/18.5-22

20-40/30-37

B1200

450-900

1200

1.3-2.0

≤18

9.5t/30m

10-20/15-18.5

20-40/22-30

B1000

280-560

1000

1.3-2.0

≤18

7.0t/25m

10-20/11-15

20-40/15-18.5

B800

130-260

800

1.3-1.6

≤18

5.3t/25m

10-20/7.5-11

20-30/11-15

B650

80-160

650

1.3-1.6

≤18

3.6t/20m

12-20/5.5-7.5

20-30/7.5-11

B500

40-80

500

1.3-1.6

≤18

3.0t/20m

12-20/4-5.5

20-30/5.5-7.5
